GERAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
5-78 Section 5-11 - Common Service Desktop (R3 only)
Virtual Console Observation
Virtual Console Observation displays the status of the VNC server. Virtual console observation (VCO)
is normally used to remotely access and modify settings and programs.
The information on Virtual Console Observation is available to Class M licenses. Virtual Console
Observation is not available through a remote connection.
To access Virtual Console Observation, select Utility (second page) > Service > Utilities > Virtual
Console Observation.
Figure 5-53 Virtual Console Observation
This table shows all the elements available on Virtual Console Observation with descriptions.
To start virtual console observation:
1.) Navigate to Utility (second page) > Service > Utilities > Disruptive Mode Utility and set
Disruptive mode to On.
2.) Navigate to Utility (second page) > Service > Utilities > Virtual Console Observation.
3.) Select Start. When VCO starts, the Windows task bar and Windows desktop display.
4.) Modify settings and programs as needed.
5.) To stop virtual console observation, click Stop. When VCO is stopped, the Windows desktop is
hidden.
6.) Restart the LOGIQ P9/P7.
For more information, see:
• Utilities on page 5-73
Table 5-32 Virtual Console Observation
Element DESCRIPTION
Status
When Disruptive mode is on, displays the status of the VNC server. Valid values are:
• VCO is stopped
• VCO is running
Start When Disruptive mode is ON, starts the VNC server.
Stop When Disruptive mode is ON and the VNC server is running, stops the VNC server.
