GEDRAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-91

3) Disconnect freeze key assy connector, trackball connector and Touch panel connectors. Refer to

following figure.

Figure 8-91 Removal of connectors on Main PWA assy

Trackball

connector

Freeze key

connector

Touch panel

connector
