8-102 Section 8-17 - Replacement around Nest Box

3) Remove 5 screws and Cable Cover Bracket.

Figure 8-107 Cable Cover Bracket

4) Disconnect Cables.

Figure 8-108 Cable Disconnecting points

Cable Cover

Bracket
