GE LOGIQ P9 Service Manual

GEDRAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
Chapter 9 - Renewal Parts 9-11
Table 9-7 User Interface
Item Part Name Part Number Description Qty FRU R1 R2 R2.5 R3
201
21.5" LCD
5501560-121 Full 21.5" LCD Monitor set with hinge 1 1 Y N N N
202
21.5 INCH LCD MONITOR
with USB 2.0 and without
glass filter
5501560-14 Full 21.5" LCD Monitor set with hinge 1 1 N Y Y N
203
MARU R3 21.5 monitor
7501560 MARU R3 21.5 monitor 1 1 N N N Y
204
21.5" LCD Cover SET
5582887
Plastics, Front, Rear and Cable cover, Monitor
USB cap, Glass Filter for 21.5" LCD
1 1 Y N N N
205
21.5 INCH LCD Cover SET
w/o glass filter
5727721
Plastics, Front, Rear and Cable cover, Monitor
USB cap
1 1 N Y Y N
206
21.5inch LCD Cover SET
R3
S5792901
Plastics, Front, Rear and Cable cover, Monitor
USB cap
1 1 N N N Y

GE LOGIQ P9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Elastography	Yes
Connectivity	DICOM, USB, Ethernet, HDMI
Doppler Modes	Color Doppler, Power Doppler
Probes	convex, linear, phased array
Imaging Modes	M-Mode, Color Doppler, Power Doppler
Portability	Cart-based
Applications	Vascular, Cardiac, OB/GYN, Musculoskeletal
Weight	Approx. 80 kg
Touch Panel	10.1-in touchscreen
