GE LOGIQ P9 Service Manual

GERAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
9-16 Section 9-7 - OPIO
320
LP7P9 OPIO MAIN BOARD
PWA SET
S5781465 LP7P9 OPIO MAIN BOARD PWA SET 1 1 N N N Y
321
Probe Light Assy
S7503830 Probe Light Assy 1 1 N N N Y
322
LP7P9 OPIO FREEZE AND P1
BOARD SET
S5781426
LP7P9 OPIO FREEZE AND P1 BOARD
SET
1 1 Y Y Y Y
323
LP7P9 OPIO 10.4 LCD Set - E
6561038 LP7P9 OPIO 10.4 LCD Set - E 1 1 N Y Y N
324
LP7P9 OPIO lower Assy - H
S5781425 LP7P9 OPIO lower Assy - H 1 1 N Y Y N
325
LP7P9 R3 OPIO lower assy
7554917 LP7P9 R3 OPIO lower assy 1 1 N N N Y
326
COMMON ROTARY
ENCODER SET FOR LP9_LP7
S5718726-2
COMMON ROTARY ENCODER SET FOR
LP9_LP7
11YYYN
327
LP7P9 R3 COMMON ROTARY
ENCODER SET
S5794055
LP7P9 R3 COMMON ROTARY ENCODER
SET
1 1 N N N Y
328
B MODE ROTARY ENCODER
SET FOR LP9_LP7
S5718727-2
B MODE ROTARY ENCODER SET FOR
LP9_LP7
1 1 Y Y Y N
329
LP7P9 R3 B MODE ROTARY
ENCODER SET
S5794057
LP7P9 R3 B MODE ROTARY ENCODER
SET
1 1 N N N Y
330
OPIO HUB BOARD PWA FOR
LP9_LP7
5503846-3 OPIO HUB BOARD PWA FOR LP9_LP7 1 1 Y Y Y N
331
Op Button_Knob Sets R3
S5794044 OP Button+Knob sets 1 1 N N N Y
332
OPIO Up_Down Button Set R3
S5794070
Up/Down Button, Rotation Button, OPIO
Dummy Button Sets
11NNNY
333
OPIO LOWER COVER R3
5794065 OPIO LOWER COVER 1 1 N N N Y
Table 9-8 OPIO
Item Part Name
Part
Number
Description
Qty FRU R1 R2 R2.5 R3

GE LOGIQ P9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Elastography	Yes
Connectivity	DICOM, USB, Ethernet, HDMI
Doppler Modes	Color Doppler, Power Doppler
Probes	convex, linear, phased array
Imaging Modes	M-Mode, Color Doppler, Power Doppler
Portability	Cart-based
Applications	Vascular, Cardiac, OB/GYN, Musculoskeletal
Weight	Approx. 80 kg
Touch Panel	10.1-in touchscreen
