Hold
the
primary
gear
with
the
gear
holder and
remove
the bolt.
Remove
the starter
clutch.
Shift
the
primary
driven
sub
gear
with a screw-
driver
to take
preload
off
the
primary
drive
gear
and
remove the
primary
drive
gear.
,
Remove the starter
driven
gear
and
needle bearing
\-
from
the starter
clutch.
lnspect
the rollers
for
smooth
operation.
Remove
the starter
clutch
cover
by
removing
the three
bolts.
Remove the
clutch
rollers,
plungers
and
springs.
Check
the
rollers
for excessive
wear.
\-
CLUTCH
SYSTEM
GEAR HOLDER 07924-MC7OOO2
or
modified
07 924
-MC7
O00
1 o r
07 924
-MC7
O0 00
o
r
07
924
4
1
SOOOO
PRIMARY
DRIVEN SUB
GEAR
PRIMARY
DRIVE GEAR
d
d
spd
STARTER
CLUTCH COVER
PRIMARY
GEAR
,;;Eate
