CRANKSHAFT/PISTON
PrsT0r{
A}rD
RoD tltsTAt
tATt0il
Clean the
piston
domes,
ring
lands, and
skirts.
Carefully install
the
piston
rings
onto the
piston.
Stagger the
ring
end
gaps
as shown.
NOTE:
'
Be careful not to damage
the
piston
and
piston
rings during assembly.
'All
rings
should be installed
with
the
markings
facing
up.
.
After installing
the
rings
they should
rotate
freely,
without sticking.
Coat
the
rod's
small
end with molybdenum disulfide
grease.
Rear
cylinders:
Note
that the
rear
cylinder connecting
rods
are
marked
"MBO-F"
or
"MB2-R"
for
the VF750F,
and
"MB1-F"
for
the VF700.
Install the
pistons
on the
rear
connecting rods
so
that the intake
"lN"
mark is
facing
opposite
the oil
hole
in the rod.
TOP
SECOND
SIDE
RAIL
SPACER
SIDE RAIL
GAP
REAR
CYLINDER
"IN"
MARK
IDENTIFICATION
MARK
V F75OF
shown.
V FTOOF:
MB1.F
12-
13
