CRANKSHAFT/PISTON
ITONITDA
V45
INTERCEPTOR
BEARTl{G
tl{SPtCTt0l{
MAIN
BEARING
Inspect the bearing
inserts for
unusual
wear
or
damage.
Reinstall
the upper
crankcase's
main
bearing
inserts,
then
carefully
lower
the crankshaft
in
place.
Wipe
all oil
from
the bearing
inserts
and
journals.
Put
a
piece
of
plastigauge
on each
journal.
NOTE
Do not
put
the
plastigauge
over the
oil hole
in
the main bearing
journal
of the
crankshaft.
Install
the main bearings
on
the correct
journals
in the lower
crankcase,
then assemble
and
tighten
the bolts evenly
in
2-3 steps in
the
sequence
shown.
TOROUE VALUES:
6
mm bolt:
10-14 N.m
(1.0-1.4
kg-m,7-10 ft-tb)
9 mm boft:
30-34
N.m
(3.0-3.4
kg-m,22-25ft-lbl
NOTE:
Do not rotate the crankshaft during inspec-
tion.
Remove
the lower
crankcase
and measure
the com-
pressed
plastigauge
on each
journal.
OIL CLEABANCE
SERVICE
LIMIT:
0.06
mm
(0.002
in)
19
2
10
8
14
I
PLASTIGAUGE
I
12-8
