Honda InterceptorVF700F - VFR75001790114.PDF

IIONIf,DA
V45 INTER,GEPTOR
SWITCHES
i\
FUEL TEYET
SE]ISOR
REMOVAL
Remove
the
fuel tank
and drain the
fuel.
Remove
the
fuel level sensor attaching
nuts and
fuel level sensor.
INSPECTION
Measure
the resistance
of the
fuel level sensor
in the
full and empty
float
positions.
RESISTANCE:
FULL
3.5-9.5
Q
EMPTY 9O-1OO
O
Turn
the ignition
switch ON.
Connect
the
fuel
level sensor
coupler
to the wire
harness.
Move the
f loat
to
full and
empty and check
the
fuel
gauge
needle
in both
positions.
lf
the fuel
gauge
does
not indicate the
proper
level. replace
it
with
a
new
one.
'""'"'^^^'i
rrr.
FULL
FUEL
GAUGE
FULL
FUEL LEVEL
SENSOR
EMPTY
2o.7
