CYLINDER
HEAD/VALVE
CYLIIIDER }|EAD ASSEI||BLY
NOTE
Install
new valve
stem seals
when
assembling.
Lubricate each
valve
stem
with molvbdenum
disulfide
grease
and insert
the
valve
into
the valve
guide.
To
avoid damage
to
the
stem
seal,
turn
the
valve
slowly
when
inserting.
Install
the
valve
springs
and
retainers. The springls
tightly wound
coils
should
face toward the
head.
Install the valve
cotters,
cAuTtot{.
To
prevent
a loss of tension, do not
com-
press
the valve spring more than necessary
to
install the valve
keepers.
Tap the
valve
stems
gently
with
a soft
hammer to
f
irmly
seat
the
cotters.
NOTE
Support the
cylinder
head
above
the work
bench surface
to
prevent possible
valve
damage.
f-r'
'if-"1
/.
il
VALVE
COTTERS
x
VALVE
STEM
SEAL
INE
R
VALVE SPRI
NG COMPRESSOR
07757-001 0000
10-
15
Date
of
lssue: January, 1983
