GENERAL
o
Some
wires have different
colored bands around
them
near
the
connector.
These are
connected to
other
wires which cor-
respond with the
band color.
o
All
plastic
plugs
have locking
tabs
that
must be
released before disconnecting,
and
must be aligned
when
reconnecting.
r
The
following color
codes
used are indicated throughout
this section
and
on the wiring
diagram.
Bu
=Blue
G
=Green
LG
=LightGreen
R
=Red
Bl
=Black
Gr
=Grey
O
=Orange
W
=White
Br
=Brown
LB
=LightBlue
P
=Pink
Y
=Yellow
o
To
isolate an
electrical
failure, check the
continuity of
the electrical
path
through
the
part.
A continuity
check can
usually
be made
without removing
the
part
from
the
motorcycle.
Simply
disconnect
the
wires and connect
a continuity
tester or
volt-ohmmeter
to
the terminals
or connections.
o
A continuitv
tester is
useful when
checking to
find
out
whether
or
not
there
is an electrical connection
between
the two
ooints.
An
ohmmeter
is needed to
measure the
resistance of a circuit,
such
as when there
is
a specific
coil resistance
involv-
ed, or
when checking
for high resistance caused
by corroded
connections.
