V45 INTERCEPTOR,
LUBRICATION
Measure the
rotor
tiP clearance.
STANDARD:
0.15
mm
(0.006
in)
SERVICE
LIMIT:
0.20
mm
(0.008
in)
Measure
the
pumP
bodY
clearance.
STANDARD
: 0.15-0.22
mm
(0'006-0.009
inl
SERVICE
LIMIT:
0.35
mm
(0'014
inl
Remove
the
rotor shaft
and
measure
the
pump
end clearance.
STANDARD:
0.02-0.07
mm
(0.001-0.003
in)
SERVICE
LIMIT:
0.10
mm
(0.004
in)
2-7
Date of
lssue: January,
1983
