FRONT WHEEL/SUSPENSION
Install
the top bridge with
the
fork
air
joint.
Instafl the
front forks
(page
14-291.
Install and
tighten the steering stem nut.
TORQUE: 90-120
N.m
(9.0-12.0
ks-m,
65-87
ft-lb)
STEERING
HEAD
BEARING PRELOAD
EXTENSION
O7716-0020500 or
EOUIVALENT
lN
U.S.A.
07716-0020400
or
EOUIVALENT lN
U.S.A,
SPRI
NG SCALE
(commerciallV
available)
lnstall the front wheel
(pale
14-17],.
Place
a stand under
the engine and
wheel off the
ground.
Position the
steering stem to the
raise
the front
straight ahead
position.
Hook a
spring scale to the fork
tube and
measure
the steering head
bearing
preload.
NOTE
Make sure that there is no cable and wire
harness interference.
The
preload
should
be within 1.0-1.6 kg
(2.21-3.53
lb) for right
and
left
turns.
lf the readings do not fall within
the range,
lower
the
front
wheel
and adjust the bearing
adjustment
nut.
After making
sure
the bearing
preload
is acceptable,
install the removed
oarts
in the reverse
order of
removat.
drl
PE
LOCK NUT WRENCH,30
x
32
mm
14-36
