}|YDRAULIC
BRA]{ES
IilONITDA
V45 INTERCEPTOR
SERI,TCE
l1{t0R]I|AT|0ll
GENERAL
o
The
brake calipers
can be removed
without disconnecting the
hydraulic system.
.
Bleed
the
hydraulic
system
if it is disassembled
or if the brake
feels
spongy.
o
Do
not
allow
foreign material
to enter the system when
filling the reservoir.
o
Avoid
spilling brake
fluid on
painted
surfaces
or instrument lenses, as severe
damage can result.
o
Always
check brake operation
before riding the motorcycle.
SPECIF
ICATIONS
TOROUE VALUES
,
Front brake caliper bracket mount
bolt
(Right)
30-40
N.m
(3.0-4.0
kg-m,22-29 ftlbl
\-
Front
brake caliper
bracket mount
bolt
(
Left-upper)
30-40
N.m
(3.0-4.0
kl-m, 22-29 ft-lbl
(Left-lower)
20-25
N.m
(2.0-2.5
kg-m, 14-18 ft-lb)
Brake caliper mount bolt
20-25
N.m
(2.0-2.5
kg-m, 14-18
ft-lb)
Brake caliper
pivot
bolt
25-30
N'm
(2.5-3.0
kg-m, 18-22 ft-lb)
Brake
hose
oil
bolt
25-40
N'm
(2.5-4.0
kg-m, 18-29 ft-lb)
Rear brake actuating arm
10-15
N'm
(1.0-1.5
kg-m, 7-11
ft-lb)
SERVICE
INFORMATION
TROUBLESHOOTING
BRAKE
FLUID REPLACEMENT/AIR
BRAKE
PAD/DISC
FRONT
MASTER CYLINDER
BRAKE
CALIPERS
REAR MASTER
CYLINDER
BLEEDING
16-
1
16- 2
16- 3
16- 5
16- 8
16-10
16-14
ITEM STANDARD
SERVICE
LIMIT
Front disc
thickness
4.5-5.2
mm
(0,
1
77
-0.205
inl
4.0
mm
(0.157
in)
Front disc runout
0.30
mm
(0.012
in)
Front master cylinder l.D. 1 5.870-1 5.913
mm
(0.6248-0.6265
in)
15.925 mm
(0.6270
n
Front master
piston
O.D.
1 5.827
-
1 5.854
mm
1O.6231
-0.6242
inl 15.815 mm
(0.6226
n
Front
caliper
piston
O.D. 31.948-31.998 mm
(
1.2578-1.2598 in) 31.940 mm
(1.2575
in
Front caliper cylinder LD.
32.030-32.080 mm
(
1.261 0-1.2630 in
32.090 mm
(1.2634
in
Rear master cylinder LD.
14.000-14.043
mm
(0.551
2-0.5529
in 14.055 mm
(0.5533
n
Rear master
piston
O.D.
13.957-13.984
mm
(0.5495*0.5506
in 13.945 mm
(0.5490
n
Rear caliper cylinder l.D.
27 .OOO-27.O50
mm
(
1.0630-1 .0650
in 27.060
mm
(1.0654
n
Rear
caliper
piston
O.D.
26.918-26.968
mm
(
1.0598-1 .061
7 in 26.910
mm
(1.0594
n
Rear
disc
thickness 6.5-7
.2
mm
(0.256-0.283
in)
6.0
mm
(0.236
in)
Rear disc runout
0.30
mm
(0.012
in)
Date
of lssue: January, 1983
O
HONDA MOTOR
CO., LTD.
16- I
