MAINTENANCE
CARBURETOR
PILOT
SCREW
wRENCH
07908-4220201
\_.
Synchronize
to specification by turning
the ad-
.iusting
screws with carburetor
pilot
screw rench
(0790842202011.
Recheck
the idle speed and synchronization.
Remove
the
gauge
adapters and install the
plugs.
CARBURETOR IOLE
SPEED
NOTE
o
Inspect
and adjust
idle
speed
after
all other
engine
adjustments
are within
specifications.
rThe
engine must
be
warm for
accurate
adjust-
ment.
Ten minutes
of stop-and-go
riding
is
sufficient.
Warm
up the engine,
shift
to NEUTRAL,
and
place
the motorcycle
on its center
stand.
Turn the
throttle
stop screw
as required
to obtain
the
specif ied
idle
speed.
IDLE
SPEED:
VF750F:
1,000
t
100 rpm
VF700F:
1,200
t
100 rpm
RADIATOR
COOLA}IT
No.3
ADJUSTING
No.1
ADJUSTING
SCBEW
SCREW
Remove
the
frame left
side cover.
Check the coolant level of the reserve tank with the
engine
runing
at
normal
operating tempqrature.
The
level
should be between the
"UPPER"
and
"LOWER"
level lines.
lf necessary,
remove the reserve tank cap and fill to
the
"UPPER"
level line
with a 50/50
mixture
of
distilled
water and anti-freeze.
Reinstall
the cap
and
frame
side cover.
,,LOWER"
MARK
No.2
ADJUSTING
SCREW
TH
ROTTLE STOP SCREW
RESERVE
TANK CAP
,,UPPER"
MARK
