V45 INTERCEPTOR
15.
REAR
II|IiIEI/SUSPENSI01I|
SERI|ICE INFORMATIO}I
GENERAL
o
The
rear wheel uses
a tubeless
tire.
SPECIFICATIONS
TOROUE VALUES
Shock
arm-to-frame
bolts
Shock
link-to-shock
arm bolt
Rear
shock absorber
mount bolts
Swingarm
pinch
bolt
Swingarm
pivot
bolts
Rear brake torque rod
Final driven
sprocket
Rear
brake
disc
Rear
axle nut
TOOLS
Special
Needle bearing remover
Oil seal
driver
attachment
Oil seal
driver
attachment ring
Oil seal
driver
Common
Attachment,
32 x 35 mm
Attachment,3T
x 40
mm
Attachment,52
x 55 mm
Attachment,
62
x
68
mm
Pilot, 17 mm
Pilot,20 mm
Pilot, 25
mm
Driver
Bearing
remover shaft
Bearing
remover head,20 mm
For
tubeless
tire
repairs,
refer to the
TUBE LESS TIRE
MANUAL.
40-50 N.m
(4.0-5.0
ks-m,
29-36 ft-lb)
40-50
N.m
(4.0-5.0
ks-m,
29-36 ft-lb)
40-50
N.m
(4.0-5.0
ks-m,
29-36 ft-lb)
20-30
N,m
(2.0-3.0
kg-m,14*22t:d-|bl
85-105
N.m
(8.5-10.5
ks-m,61-76
ft-lb)
18-25
N.m
(1.8-2.5
ks-m, 13-18ft-lb)
30-40 N.m
(3.0-4.0
kg-m,
22-29
ft-lbl
80-100
N.m
(8.0-10.0
ks-m,58-72 ft-lb)
35-40
N.m
(3.5-4.0
kg-m,
25-29
ft-lb)
85-105
N.m
(8.5-10.5
kg-m,
61-76
ft-lb)
8mm
10
mm
07931
-MA70000
07965-MC701
00
07965-ME701 00
07965-M 8001 00
07746-001 01 00
07746-0010200
07746-001 0400
07746-001 0500
07746-0040400
07746-0040500
07746-0040600
07749-001
0000
07746-0050100
or equivalent
in
U.S.A.
07746-0050600
or equivalent
in U.S.A.
SERVICE
INFORMATION
TROUBLESHOOTING
REAR WHEEL
SHOCK ABSORBER
SWINGARM
15-1
15-2
15-3
15-8
15-13
STANDARD
SERVICE LIMIT
Axle
runout
0.2
mm
(0.01
in)
Rear wheel rim
runout
Rad ial
2,0 mm
(0.08
in)
Axial
2.0 mm
(0.08
in)
Shock absorber
air
pressure
50-300 kPa
(0.5-3.0
kg/cmz, 7-43
psi)
Date
of lssue:
October, 1983
O HONDA
MOTOR
CO.. LTD.
15- 1
