GEARSHIFT
LINKAGE
OTARS}|ITT
tII{I(AGT RE]||O['AT
Drain
the engine
oil
{page
2-3).
Remove the
gearshift
arm
from
the shift shaft.
Remove the
clutch cover and clutch
assembly
(Section
7).
Remove the oil
pump
driven
sprocket
bolt.
Remove
the oil
pump
drive chain, drive and driven
sorockets.
Remove
the drum stopper
collar, and
arm.
arm
nut, washer,
spring,
GEARSHIFT
ARM
SHIFT SHAFT
OIL
PUMP
DR IVE
RIVE
SPROCKET
OIL
PUMP DRIVEN
SPROCKET
BOL
DRUM
STOPPER
ARM
8-2
