VF7OOI750 INTERCEPTOR
MAINTENANCE
lgnition timing
At idle:
Advance
starts:
Full advance:
VF75OF:1O"BTDC
VFTOOF:1s"BTDC
1,500 rpm
37"BTDC at 3,300
rpm
Valve
clearance
Cold
(Below
35'C, 95oF):
Intake/Exhaust:
0.12 mm
(0.005
in)
ldle speed:
VF750F:
1,000
t
100
rpm
VF700F: 1,200
t
100
rpm
Carburetor
synchronization:
All carburetors
within
60
mm
12.4
inl Hg
of each
other
Cylinder compression:
1,300
t
200
kPa
(.13.0
t
2.Okglcm2,185
r
28
psi)
Throttle
grip
free
play:
2-6 mm
(118-114
inl
< CHASSIS
>
Drive
chain slack:
15-25 mm
(5/8-1
in)
Tires:
Tire
size
F ront
Rear
M120/80-16
M 130/80-18
Cold
tire
pressure,
kpa
(kg/cm2,
psi)
Up
to
90 kS
(200
lbs)
load
22512.25,321
22512.25,32l.
90
kg
(200
lbs)
load
to vehicle capacity load
22512.25,321
280
(2.80,
40)
Tire
brand
Bridgestone
G51
1
G510
Dunlop F11
K627
Suspension air
pressure:
Front,
0-40
kPa
(0-0.4
kglcm2, 0-6
psi)
Rear,
so-300
kPa
(0.5-3.0
kg/cm2,
7-43
psi)
TOOLS
Special
Vacuum
gause
07404-0030100
or
07404-0020000
or M937B-021-XXXXX
(U.S.A.
onty)
Carburetor
pilot
screw
wrench 079084220201
\
Compression
gauge
attachment
07510-M800101
\-,
Common
Lock nut wrench,
10 x
12 mm
07708-0030200
or equivalent
in
U.S.A.
Date of lssue: June, 1984
@American
Honda
Motor
Co., Inc.
1984
-
All Rights
Reserrad
3-2
