V45 INTERCEPTOR
HYDRAULIC
BRAKE
BRAKE
PAD/DISC
FRONT
PAD REPLACEMENT
NOTE
Always
replace
the brake
pads
in
pairs
to
assure
even
disc
pressure.
Remove
the
pad pin
retainer
bolt.
Right
caliper: Remove
the caliper
bolt
bolt.
Left
caliper: Remove
the
caliper
pivot
anti-dive
link
bolt.
Remove
the caliper
from
the
bracket.
and
pivot
bolt and
Remove
the
pad pin
retainer
and
pull
the
pad
out
of the
caliper.
Remove
the
brake
pads.
Position
the
pad
spring
in the
caliper
as shown.
Push the
caliper
pistons
in
all
the
way.
prns
LEFT CALIPER
PAD
PINS
PAD SPRING
16-5
Date
of lssue:
January, 1983
