SWITCHES
IGNITION
SWITCH DISASSEMBLY
Insert
the key
and
turn it
so
it is
part
way between
the
"ON"
and
"OFF"
detent
positions.
Pry
open
the wire retainer.
Push
in the
lugs that
are
locked
in the slots,
then
pull
the contact
base
{rom
the switch.
Assemble
in
the reverse
order of removal.
FlJEL
PUltlP
Turn
the
f
uel
valve and
ignition
switch
off.
Remove
the
frame
side
covers, seat
and
fuel tank.
Disconnect
the fuel
pump
relay coupler and short
the
white
and
black
wire
terminals
with a
lumper
wire.
Disconnect
the
fuel
line at
the
fuel line
joint
and
hold
a
graduated
beaker
under
the outlet
tube.
Reinstall
the
fuel tank.
Turn
the
ignition switch
on and
let
fuel
flow into
the
beaker
for 5 seconds,
then turn
the ignition
switch
off.
Multiply
the amount
in the beaker
by 12
to determine
the
fuel
pump
flow
capacity
per
minute.
FUEL
PUMP
FLOW CAPACITY:
660cc
(22
US
oz, 18.6
lmp
ozl
t
1O%/minute
NOTE
Use a
fully
charged
battery
or
f alse
readings
may
result.
Battery
voltage should
be above
12.5
V.
lf the
fuel
pump
flow
capacity
is below
the specif
i-
cation,
measure
the voltage
at the
fuel
pump
coupler'
Replace the
fuel
pump
if battery
voltage is
present.
FUEL
PUMP
RTLAY
Check
for
a
burnt sub-fuse.
Check the
relay coupler
for
improper contact
and
looseness.
Measure the voltage between
the
relay black wire
and
a
body
ground.
The
battery voltage should
register with
the ignition
switch
ON.
Make
sure
that
the
fuel
pump
operates
while
the
relay
coupler
black and
white wires are shorted and
the
ignition siruitch
is
ON.
lf the
pump
does not
operate,
check
the fuel
pump
coupler
for
improper contact
and the fuel
pump.
Check
for
continuity
between
the ignition
control
unit blue wire and the
fuel
pump
relay coupler blue
wire. lf there
is
continuity,
replace
the fuel
pump
relay. lf there
is no continuity,
replace
the wire har-
ness.
FUEL
PUMP
RELAY
VOLTMETER
\z'':-*
FUEL
PUMP
RELAY
\ z,--.-\
\ -\ffii I
\ry*I
l l
/\u
JUMPER WIRE
