HPE FlexNetwork MSR Series User Manual

108
Figure 107 Displaying detailed radio information
Table 63 Field description
Field Description
WLAN-Radio1/0 current state: UP State of the radio interface.
IP Packet Frame Type Output frame encapsulation type.
Hardware Address MAC address of the radio interface.
Radio-type dot11a WLAN protocol type used by the interface.
channel
Channel used by the interface. The keyword
auto
means the
channel is automatically selected.
If the channel is manually configured, the field will be
displayed in the format of
channel
configured-channel.
power(dBm) Transmit power of the interface (in dBm).
Received: 2 authentication frames, 2
association frames
Number of authentication and association frames received.
Sent out: 2 authentication frames, 2
association frames
Number of authentication and association frames sent.
Stations: 0 associating, 2 associated
Number of stations being associating and stations having
been associated.
Input : 70686 packets, 6528920 bytes
: 255 unicasts, 34440 bytes
: 70461 multicasts/broadcasts,
6494480 bytes
: 0 fragmented
: 414 discarded, 26629 bytes
: 0 duplicates, 3785 FCS errors
: 0 decryption errors
Input packet statistics of the interface:
• Number of packets, number of bytes.
• Number of unicast packets, number of bytes of unicast
packets.
• Number of multicasts/broadcast packets, number of
bytes of multicasts/broadcast packets.
• Number of fragmented packets.
• Number of discarded packets, number of discarded
bytes.
• Number of duplicate frames, number of FCS errors.
• Number of encryption errors.
