HPE FlexNetwork MSR Series User Manual

131
Item Description
Network selection mode
Network selection mode:
• Manual.
• Automatic.
MCC Mobile Country Code. For example, the MCC of Mainland China is 460.
MNC Mobile Network Code. For example, the MNC of China Mobile is 00.
LAC Location Area Code.
CELL ID Cell ID.
PDP status PDP status of the 3G/4G modem.
Service Status
Service status of the 3G/4G network:
• Available.
• Not available.
Current Roaming Status
Roaming status:
• Roaming.
• Home.
Signal strength Signal strength of the 3G/4G network.
Configured LTE bands LTE bands configured for the SIM card.
Current LTE bands LTE bands of the 3G/4G network.
Table 83 3G network information (CDMA)
Item Description
Service Provider Service provider of the 3G network that the UIM card accesses.
Network type 3G network type.
Service Status
(1xRtt)
Service status of the 3G network (1xRtt):
• Available.
• Not available.
Roaming Status
(1xRtt)
Roaming status of the 3G network (1xRtt):
• Home.
• Roaming.
RSSI (1xRtt) Received signal strength indication of the 3G network (1xRtt).
Service Status
(Evdo)
Service status of the 3G network (Evdo):
• Available.
• Not available.
Roaming Status
(Evdo)
Roaming status of the 3G network (Evdo):
• Home.
• Roaming.
RSSI (Evdo) Received signal strength indication of the 3G network (Evdo).
Configuring the cellular interface
1. Click the icon for the cellular interface on the page shown in Figure 133.
2. On the cellular interface configuration page, click the Interface tab.
