HPE FlexNetwork MSR Series User Manual

251
Item Description
Group Name
Select an SNMP group to which the user belongs:
• When the security level is NoAuth/NoPriv, you can select an SNMP
group with no authentication no privacy.
• When the security level is Auth/NoPriv, you can select an SNMP group
with no authentication no privacy or authentication without privacy.
• When the security level is Auth/Priv, you can select an SNMP group of
any security level.
Authentication Mode
Select an authentication mode (including MD5 and SHA) when the security
level is Auth/NoPriv or Auth/Priv.
Authentication
Password
Set the authentication password when the security level is Auth/NoPriv or
Auth/Priv.
The confirm authentication password must be the same with the
authentication password.
Confirm Authentication
Password
Privacy Mode
Select a privacy mode (including DES56, AES128, and 3DES) when the
security level is Auth/Priv.
Privacy Password
Set the privacy password when the security level is Auth/Priv.
The confirm privacy password must be the same with the privacy password.
Confirm Privacy
Password
ACL
Associate a basic ACL with the user to restrict the source IP address of
SNMP packets. To allow or prohibit the specified NMS to access the agent
by using this user name, you can allow or prohibit SNMP packets with a
specific source IP address.
Configuring the SNMP trap function
1. Select Advanced > SNMP from the navigation tree, and click the Trap tab to enter the page as
shown in Figure 264.
On the upp
er
part of the page, you can select to enable the SNMP trap function.
On the lower part of the page, you can configure target hosts of the SNMP traps.
Figure 264 Traps configuration
2. Click Add to enter the Add Trap Target Host page, as shown in Figure 265.
