98
Figure 92 Checking the wireless service list
Connecting the wireless service
1. Method 1
Click the Connect icon of the wireless service in the wireless service list, and a SET CODE
dialog box shown in Figure 93 appe
ars.
Figure 93
Setting a code
The following authentication modes are supported:
Open System
Shared key
RSN + PSK
Table 58 Configuration items
Item Description
AuthMode
Specify the network authentication mode, which can be:
• Open System—Open system authentication, namely, no
authentication
• Shared Key—Shared key authentication, which requires
the client and the device to be configured with the same
shared key.
• RSN+PSK—PSK authentication
CipherSuite
Set the data encryption mode, which can be:
• Clear—No encryption
• WEP—WEP encryption
• TKIP/CCMP—TKIP/CCMP encryption
Password Configure the WEP key
