Figure 290 Configuring interface
Table 129 Configuration items
Item Remarks
Interface Select the interface you want to configure.
Bridge Group Set the ID of the bridge set to which you want add the interface.
VLAN Transmit
Enable or disable VLAN transparency on the interface.
Hewlett Packard Enterprise recommends not enabling this function on a
subinterface.
A VLAN interface does not support this function.
Bridging configuration example
Network requirements
As shown in Figure 291, the trunk ports of Switch A and of Switch B are assigned to the same VLAN.
Enable VLAN transparency on Ethernet interfaces of the two routers, so the two office areas can
communicate within the same VLAN.
