49
Figure 412 Adding a user-IP binding
4. Configure the user-IP binding as described in Table 174.
5. Click Apply.
Table 174 Configuration items
Item Description
Username
Specify the username to be bound with an IP address. The username must contain
the domain name. For example,
aaa@local
.
IP Address
Specify the IP address to be bound with the username.
The specified IP address must be in the same network segment as the global IP
address pool and must not be the gateway address or any address in the global IP
pool.
Configuring a predefined domain name
1. Select VPN > SSL VPN > Resource Management > IP Network from the navigation tree.
2. Click the Predefined Domain Name tab to view existing predefined domain names.
Figure 413 Predefined domain names
3. Click Add to enter the page for adding a predefined domain name
Figure 414 Adding a predefined domain name
