232
Configuring interface bandwidth
Select Advance > QoS Setup > Advanced Queue from the navigation tree to enter the Advanced
Queue page. Select an interface from the Interface Name list, and then configure and view the CIR
of the interface.
Figure 243 Advanced queue
Table 117 Configuration items
Item Description
Interface Name Select the interface to be configured.
Interface Bandwidth
Set the average traffic rate allowed for the interface.
Hewlett Packard Enterprise recommends that you configure the interface
bandwidth to be smaller than the actual available bandwidth of a physical
interface or logical link.
If you have specified the interface bandwidth, the maximum interface
bandwidth used for bandwidth check when CBQ enqueues packets is 1000000
kbps. If you have not specified the interface bandwidth, the maximum interface
bandwidth varies by interface type following these rules:
• If the interface is a physical one, the actual baud rate or rate applies.
• If the interface is T1/E1, MFR or any other type of logical serial interface
formed by timeslots or multiple links, the total bandwidth of all member
channels/links applies.
• If the interface is a template interface, such as a VT interface, a dialer
interface, a BRI interface, or a PRI interface, 1000000 kbps applies.
• If the interface is a virtual interface of any other type, a tunnel interface for
example, 0 kbps applies.
