53
Item Description
Interface Status
Display and set the interface status:
• Connected—Indicating that the current interface is up and connected, click
Disable to shut down the interface.
• Not connected—Indicating that the current interface is up but not connected,
click Disable to shut down the interface.
• Administratively Down—Indicating that the current interface is shut down
by a network administrator, click Enable to bring up the interface.
Work Mode: CT1 Select CT1 as the operating mode.
Operation
Add or remove timeslots.
• create—Adds timeslots to form a channel set.
• delete—Removes timeslots from a channel set.
Serial Specify the serial interface number of the channel set.
Timeslot-List Set the timeslots to add or remove.
User Name Configure the username for authentication.
Password
Displays whether a password is configured for authentication.
If the field displays null, no password is configured for authentication.
New Password Set or modify the password for authentication.
TCP-MSS Configure the TCP MSS on the interface.
MTU Configure the MTU on the interface.
Displaying interface information and statistics
On the WAN Interface Setup page as shown in Figure 28, you can view the name, connection type,
IP address, mask, and status of each interface.
To view statistics for an interface, click the interface name.
