42
Figure 29 Configuring an Ethernet interface
Table 24 Configuration items (auto mode)
Item Description
WAN Interface Displays the name of the Ethernet interface to be configured.
Interface Status
Display and set the interface status:
• Connected—Indicating that the current interface is up and connected, click
Disable to shut down the interface.
• Not connected—Indicating that the current interface is up, but not
connected, click Disable to shut down the interface.
• Administratively Down—Indicating that the current interface is shut down
by a network administrator, click Enable to bring up the interface.
Connect Mode: Auto
Select
Auto
as the connection mode. The interface will get an IP address
automatically.
MAC Address
Set the MAC address of the Ethernet interface using one of these available
options:
• Use the MAC address of the device—Use the default MAC address of the
Ethernet interface, which is displayed in the following brackets.
• Use the customized MAC address—Manually set the MAC address of the
Ethernet interface. When you select this option, you must enter a MAC
address in the field below.
