45
Figure 30 Configuring an SA interface
Table 27 Configuration items
Item Description
WAN Interface Displays the name of the interface to be configured.
Interface Status
Display and set the interface status:
• Connected—Indicating that the current interface is up and connected, click
Disable to shut down the interface.
• Not connected—Indicating that the current interface is up but not connected,
click Disable to shut down the interface.
• Administratively Down—Indicating that the current interface is shut down by a
network administrator, click Enable to bring up the interface.
User Name Configure the username for authentication.
Password
Displays whether a password is configured for authentication.
If the field displays null, no password is configured for authentication.
New Password Set or modify the password for authentication.
TCP-MSS Configure the TCP MSS on the interface.
MTU Configure the MTU on the interface.
IP Address Configure the IP address for the interface.
IP Mask Configure the subnet mask for the interface.
Configuring an ADSL/G.SHDSL interface
Overview
The ADSL interface and the G.SHDSL interface support IPoA, IPoEoA, PPPoA, and PPPoEoA.
