Item Description

Time Range

Select the time range during which the rule takes effect.

The time ranges available for selection must have been created at the CLI on the

router.

Configuring a rule for an advanced IPv4 ACL

Select Advanced > QoS Setup > ACL IPv4 from the navigation tree and then select the Advanced

Config tab to enter the rule configuration page for an advanced IPv4 ACL.
