SSL VPN configuration example
Network requirements
As shown in Figure 445, request a certificate and enable SSL VPN service on the SSL VPN gateway
so that users can use HTTPS to log in to the SSL VPN gateway to access the internal resources of
the corporate network.
In this configuration example:
• In this example, the CA runs the Windows Server and the SCEP plugin is required on the CA.
• The IP address of the SSL VPN gateway is 10.1.1.1/24. The IP address of the CA is 10.2.1.1/24,
and the name of the CA is CA server. The CA is used to issue certificates to the SSL VPN
gateway and remote users.
• Perform RADIUS authentication for SSL VPN users. The IP address of the RADIUS server (a
CAMS/IMC server) is 10.153.10.131/24. After passing authentication, an SSL VPN user can
access the internal technology website whose IP address is 10.153.1.223, all hosts on subnet
10.153.2.0/24, and the security sever whose IP address is 10.153.2.25 through the FTP
shortcut.
• Configure a public account named usera. Specify that only one user can use the public account
to log in at a time. Configure local authentication for the public account and authorize a user
who logs in by using the public account to access the shared desktop provided by internal host
10.153.70.120.
• Specify the default authentication method as RADIUS for the SSL VPN domain and enable
verification code authentication.
Figure 445 Network diagram
Configuration prerequisites
• The SSL VPN gateway, the CA, and the hosts used by remote users can reach each other.
• The CA is enabled with the CA service and can issue certificates to the SSL VPN gateway and
the hosts.
• The RADIUS server is correctly configured to provide normal authentication function for users.
In this example, you need to configure the shared key as expert, configure the user account
and user group information, and add users to user group user_gr2.
Device
SSL VPN gateway
Host
Remote user
Internal servers
CA
Internet
10.2.1.1/24
10.1.1.1/24
