a. Enable CAC for AC_VI in the same way: select Interface Setup > Wireless > Wireless
QoS from the navigation tree, click the QoS Service tab, find the radio unit to be configured
in the list, and click the corresponding icon in the Operation column.
Figure 125 Setting CAC client number
j. Select the Client Number option, and then input 10.
k. Click Apply.
Verifying the configuration
If the number of existing clients in the high-priority ACs plus the number of clients requesting access
is smaller than or equal to the user-defined maximum number of users allowed in high-priority ACs,
which is 10 in this example, the request is allowed. Otherwise, the request is rejected.
Static rate limiting configuration example
Network requirements
As shown in Figure 126, two clients access the WLAN through a SSID named service1. Limit the
maximum bandwidth per client to 128 kbps on the device.
Figure 126 Network diagram
Configuration procedure
1. Configure the access service:
For the configuration procedure, see "Wireless access service configuration examples." You ca
n
strictly follow the related configuration example to configure the wireless service.
2. Configure static rate limiting:
a. Select Interface Setup > Wireless > Wireless QoS from the navigation tree.
b. Click Client Rate Limit.
c. Click Add.
