99
Item Description
KeyID
There are four static keys in WEP. Their key indexes are 1, 2, 3,
and 4. The key corresponding to the specified key index will be
used for encrypting and decrypting frames.
2. Method 2
You can also enter a wireless service to specify the wireless service to be connected on the
page displayed after clicking the Connect icon of the wireless service.
Figure 94 Associating the specified wireless service
Enter the specified wireless service in the Wireless Service Name field, and click Connect.
Then the dialog box in Figure 93 app
ea
rs. Set the options on the dialog box according to the
specified wireless service type.
Displaying statistics
Select Interface Setup > Wireless Service > Client Mode from the navigation tree and click
Statistic Information.
Figure 95 Displaying statistics
Client mode configuration example
Network requirements
As shown in Figure 96, the router accesses the wireless network as a client. The Ethernet interface of
the router connects to multiple hosts or printers in the wired network, and thus the wired network is
connected to the wireless network through the router.
• The AP accesses the wired LAN, and the router accesses the AP as a client.
• The router accesses the wireless service psk by passing the RSN(CCMP)+PSK authentication.
• Client with MAC address 0014-6c8a-43ff also accesses the wireless service psk.
