Creating a VLAN and its VLAN interface
Select Interface Setup > LAN Interface Setup from the navigation tree. The system goes to the
default page, VLAN Setup page.
Figure 36 VLAN setup page
Table 35 Configuration items
Item Description
VLAN Create And
Remove
Set the operation type to
Create
or
Remove
.
VLAN IDs
Enter the ID of the VLAN (or VLAN interface) to be created or removed. You
can create or remove multiple VLANs at a time.
Create VLAN Interface Create a VLAN interface when you create a VLAN.
Only Remove VLAN
Interface
Remove the VLAN interface of a VLAN without removing the VLAN.
Configuring VLAN member ports
The ports that you assign to a VLAN in the Web interface can only be set to untagged type.
The VLAN member port list displayed on the VLAN Setup page includes both tagged and untagged
member ports.
You can configure a VLAN by assigning ports to it or removing ports from it.
