252
Figure 265 Adding a target host of SNMP traps
3. Configure the SNMP traps, as shown in Table 127.
Table 127 Configuration items
Item Description
Destination IP Address
Set the destination IP address.
Select the IP address type: IPv4/domain name or IPv6, and then type
the corresponding IP address or domain name in the field according
to the IP address type.
Security Name
Set the security name, which can be an SNMPv1 community name,
an SNMPv2c community name, or an SNMPv3 username.
UDP Port
Set UDP port number.
IMPORTANT:
The default port number is 162, which is the SNMP-specified port
used for receiving traps on the NMS. Generally (such as using IMC or
MIB Browser as the NMS), you can use the default port number. To
change this parameter to another value, make sure the configuration
is the same with that on the NMS.
Security Model
Select the security model, the SNMP version.
IMPORTANT:
The security model must be the same as that running on the NMS.
Otherwise, the NMS cannot receive any trap.
Security Level
Set the authentication and privacy mode for SNMP traps when the
security model is selected as
v3
. The available security levels are: no
authentication no privacy, authentication but no privacy, and
authentication and privacy.
If you select
v1
or
v2c
in the
Security Model
list, the security level
can only be
no authentication no privacy
, and cannot be modified.
Displaying SNMP packet statistics
Select Advanced > SNMP from the navigation tree to enter the Setup tab page. On the lower part of
the page, you can view the SNMP statistics, as shown in Figure 266.
