285
Figure 670 Configuring address hiding
3. Configure the address hiding function as described in Table 249.
Table 249 Configuration items
Item Description
Address hiding
Specify the address hiding function enables the SIP trunk device to replace the
endpoints' addresses carried in SIP messages with the addresses of the
corresponding egress interfaces.
• Enable—Enable the address hiding function.
• Disable—Disable the address hiding function.
By default, the
Disable
option is selected.
Specifying the outbound proxy
1. Select Voice Management > Call Connection > SIP Connection from the navigation tree.
2. Click the Advanced Settings tab.
The page for configuring advanced settings appears.
Figure 671 Configuring outbound proxy
3. Specify the proxy server used for outbound calls as described in Table 250.
Table 250 Configuration items
Item Description
Address Specify the IP address or domain name of the proxy server.
Port Specify the port number of the proxy server.
Configuring registration parameters
Select Voice Management > Call Connection > SIP Connection from the navigation tree, and
click the Advanced Settings tab to access the configuration page as shown in Figure 672.
