HPE FlexNetwork MSR Series User Manual

223
Table 113 Configuration items
Item Description
ACL
Select the advanced IPv4 ACL for which you want to configure
rules.
You can use command line interface to create advanced IPv4
ACLs. For more information, see HPE FlexNetwork MSR
Router Series Comware 5 ACL and QoS Configuration Guide.
Also, when you configure advanced bandwidth limit and
advanced bandwidth guarantee, the system automatically
creates advanced IPv4 ACLs. For more information, see
"Configuring QoS."
Rule ID
Select the
Rule ID
box, and enter a number for the rule.
If you do not specify the rule number, the system assigns one
automatically.
If the rule number you specify already exists, the following
operations modify the configuration of the rule.
Action
Select the action to be performed for IPv4 packets matching
the rule:
• Permit—Allows matched packets to pass.
• Deny—Drops matched packets.
Non-First Fragments Only
Select this box to apply the rule to only non-first fragments.
If you do not select this box, the rule applies to all fragments
and non-fragments.
Logging
Select this box to keep a log of matched IPv4 packets.
A log entry contains the ACL rule number, operation for the
matched packets, protocol that IP carries, source/destination
address, source/destination port number, and number of
matched packets.
IP Address
Filter
Source IP Address
Select the
Source IP Address
box, and enter a source IPv4
address and source wildcard, in dotted decimal notation.
Source Wildcard
Destination IP Address
Select the
Source IP Address
box and enter a source IP
address and source wildcard, in dotted decimal notation.
Destination Wildcard
Protocol
Select the protocol to be carried by IP.
If you select
1 ICMP
, you can configure the ICMP message
type and code. If you select
6 TCP
or
17 UDP
, you can
configure the TCP or UDP specific items.
ICMP Type
ICMP Message Specify the ICMP message type and code.
These items are available only when you select
1 ICMP
from
the
Protocol
list.
If you select
Other
from the
ICMP Message
list, you must
enter values in the
ICMP Type
and
ICMP Code
fields.
Otherwise, the two fields will take the default values, which
cannot be changed.
ICMP Type
ICMP Code
TCP/UDP Port
TCP Connection
Established
Select this box to make the rule match packets used for
establishing and maintaining TCP connections.
These items are available only when you select
6 TCP
from
the
Protocol
list.
A rule with this item configured matches TCP connection
packets with the ACK or RST flag.
