HPE FlexNetwork MSR Series

4
Item Description
Source
Address/Wildcard
• Characteristics of Traffic—Identifies traffic to be protected based on the
source address/wildcard and destination address/wildcard specified.
• Designated by Remote Gateway—The remote gateway determines the
data to be protected.
IMPORTANT:
• To make sure SAs can be set up, configure the source address/wildcard on
one peer as the destination address/wildcard on the other, and the
destination address/wildcard on one peer as the source address/wildcard on
the other. If you do not configure the parameters this way, SAs can be set up
only when the IP addresses configured on one peer are subsets of those
configured on the other and the peer with the narrower address range
initiates SA negotiation.
• If the data range is designated by the remote gateway, the local peer cannot
initiate a negotiation.
Destination
Address/Wildcard
Reverse Route
Injection
Enable or disable IPsec RRI. When enabling IPsec RRI, you can specify a next
hop and change the preference of the static routes.
After an outbound IPsec SA is created, IPsec RRI automatically creates a static
route to the peer private network. You do not have to manually configure the static
route.
IMPORTANT:
• If you enable IPsec RRI and do not configure the static route, the SA
negotiation must be initiated by the remote gateway.
• IPsec RRI creates static routes when IPsec SAs are set up, and delete the
static routes when the IPsec SAs are deleted.
• To view the static routes created by IPsec RRI, select Advanced > Route
Setup [Summary] from the navigation tree.
Next Hop
Specify a next hop for the static routes.
If you do not specify any next hop, the remote tunnel endpoint’s address learned
during IPsec SA negotiation is used.
Priority
Change the preference of the static routes.
Change the route preference for equal-cost multipath (ECMP) routing or route
backup. If multiple routes to the same destination have the same preference,
traffic is balanced among them. If multiple routes to the same destination have
different preference values, the route with the highest preference forwards traffic
and all other routes are backup routes.
4. Click Advanced Configuration to expand the advanced configuration area.
