HPE FlexNetwork MSR Series User Manual

216
Figure 599 Network diagram
Configuration procedure
Before performing the following configuration, make sure that Router A, Router B and Router C are
routable to each other.
1. Complete basic voice call configurations: complete basic voice call configurations on Router A,
Router B, and Router C.
2. Configure three-party conference.
# Enable call hold on Router A and Router C.
a. Select Voice Management > Local Number from the navigation tree, click the icon of
the local number to be configured to access the call services configuration page.
Figure 600 Configuring call hold
b. Select Enable for Call Hold.
c. Click Apply.
# Enable call hold and three-party conference on Router B.
d. Select Voice Management > Local Number from the navigation tree, click the icon of
local number 2000 in the local number list to access the call services configuration page.
1000
Eth1/0
10.1.1.1/24
3000
Router A
Eth1/0
20.1.1.2/24
2000
Eth1/0
10.1.1.2/24
Eth1/1
20.1.1.1/24
Router B Router C
Telephone B
Telephone C
Telephone A
