334
Table 268 Configuration items
Item Description
Physical Parameters Configuration
Working Mode
Configure the working mode of the T1 interface:
None—Remove the existing bundle.
PRI Trunk Signaling—Bundle timeslots on a T1 interface into a PRI group.
By default, no PRI group is created.
Bound Timeslot
Number
Specify the timeslots to be bundled.
Frame Check Mode
ESF—Perform extended super frame (ESF).
SF—Perform super frame (SF).
Line Coding
B8ZS—The line coding format is bipolar 8 zero substitution (B8ZS).
AMI—The line coding format is alternate mark inversion (AMI).
TDM Clock Source
Internal—Set the internal crystal oscillator TDM clock as the TDM clock
source on the T1 interface. After that, the T1 interface obtains clock from the
crystal oscillator on the main board. If it fails to do that, the interface obtains
clock from the crystal oscillator on its T1 card. Because SIC cards are not
available with crystal oscillator clocks, T1 interfaces on SIC cards can only
obtain clock from the main board. The internal clock source is also called
master clock mode in some features.
Line—Set the line TDM clock as the TDM clock source on the T1 interface.
After that, the T1 interface obtains clock from the remote device through the
line. The line clock source is called as slave clock mode in some features.
Line primary—Set the T1 interface to preferably use the line TDM clock as
the TDM clock source. After that, the T1 interface always attempts to use the
line TDM clock prior to any other clock sources.
By default, the TDM clock source for a T1 interface is the internal clock.
When digital voice T1 interfaces perform TDM timeslot interchange, it is important
for them to achieve clock synchronization to prevent frame slips and bit errors.
Depending on your configurations on T1 interfaces at the CLI, the system adopts
different clocking approaches. When there is a subcard VCPM on the main board,
the clock distribution principle is as follows:
If the line keyword is specified for all interfaces, the clock on the interface
with the lowest number is adopted. In case the interface goes down, the clock
on the interface with the next second number is adopted.
If line primary is specified for interface X and line or internal is specified for
other interfaces, the clock on interface X is adopted.
If line is specified for interface X and internal is specified for other interfaces,
the clock on interface X is adopted.
Generally, you cannot set the clock source for all interfaces in a system as
internal to prevent frame slips and bit errors. However, you can do this if the
remote T1 interfaces adopt the line clock source.
When there is no VCPM on the main board, the configuration of each MIM/FIC is
independent but only one interface can be set as
line primary
.
Status
Enable—Enable the T1 interface.
Disable—Disable the T1 interface.
If you select the PRI Trunk Signaling option, the page as shown in Figure 723 appears.
