Router winch mount with winch strap plate
To install the router transport kit:
1. Remove the router transport kit from the shipping crate (see “Unpacking the Router Transport Kit” on
page 235).
NOTE: The router transport kit weighs approximately 138.5 lb (62.82 kg).
2. Remove the winch strap plate that is secured to the winch mount using a 9/16-in. (14 mm) socket
wrench, and set aside.
3. Using a number 3 Phillips screwdriver, loosen the captive screws that secure the winch mount to the
router transport kit, and set aside.
4. Using a number 3 Phillips screwdriver, loosen the captive screws that secure the router transport
mounting plate and wheel assembly (left and right) to the router transport platform, and set them aside
(see Figure 103 on page 266).
Figure 103: Preparing the Router Transport Kit for Installation
266
