NOTE: Make sure the bubbles within the T-shaped levels are between the lines, indicating
the router is level.
5. Adjust the four leveling mounts on the router transport platform until all four leveling mounts rest
firmly on the ground (see Figure 109 on page 273).
Figure 109: Align the MX2020 Router with Rack Mounting Shelf
6. Unlock the four toggle latches that secure the router transport platform to the router transport mounting
plates and wheel assembly.
7. Lift the wheels up by turning the handles counterclockwise so that the weight of the router is on the
router transport platform.
8. Using a number 3 Phillips screwdriver, loosen the captive screws that secure the router transport
mounting plate and wheel assembly to the chassis, and set them aside (see Figure 110 on page 274).
273
