NOTE: A minimum of 42 in. (106.7 cm) of circular space is required to rotate the chassis.
NOTE: The router transport kit handles can be removed to accommodate aisle width.
3. Install the winch mount bracket to the rear rack rails using the captive screws, and tighten (see
Figure 108 on page 272).
Figure 108: Installing Winch Mount Bracket to Rack Rails
4. Adjust the height of the router by turning the handles clockwise until the router transport platform is
aligned with the surface of the mounting shelf and slightly higher than the mounting shelf (see
Figure 109 on page 273).
272
