Figure
185:
Attaching
the
Power
Cord
Retainer
•
Secure
the
power
cord
retainer
to
the
PDM
by
threading
the
two
screws
at
each
end
of
the
power
cord
retainer
into
the
screw
holes
on
the
PDM
and
turning
them
clockwise
to
tighten.
•
Verify
that
the
PDM
looks
like
the
illustration
shown
in
Figure
186
on
page
389
Figure
186:
Proper
Installation
of
the
MX2000
Single-Phase
AC
Power
Distribution
Module
in
Chassis
(nine-feed)
389
