Overview
■ Making the electrical connection (a spare input for the remote contact is to be found in the
electrical wiring diagram for the machine, DI 1.07 being preferred).
■ Switching machine start to remote mode.
■ Activating the «remote control» key.
■ Activating the «Time control» key and configure the clock program (see chapter 8.5.1.2), if
necessary.
■ Assigning a different input for the remote contact RC , if required.
■ Pressing the «Remote control» key.
8.5.3.1 Switching machine start to Remote mode
Two methods are available to start the machine remotely from a control center:
■ Variant A: Starting the machine with the input signal from the remote control center.
■ Variant B: Starting the machine from the remote control center in addition to a configured
ON/OFF clock program.
The machine can be started from the remote control center even though the timer control is
activated and the ON/OFF program has selected OFF at this point in time.
Precondition The electrical connection has been made.
Password access level 2 is activated.
The operating mode is displayed.
1. Open the 5.4.1 <Configuration – Compressor start – Compressor on> menu.
2. Use «Up» or «Down» to select the Remote mode line.
3. Press the «DOWN» key.
4. Press «Enter».
The currently active operating mode flashes.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.4.1 Compressor on
Menu
Local mode:
Key
Remote mode:
Key
Active line
------------------------------
RC DI1.07 ok ☑
5. Use «Up» or «Down» to set the Key + remote contact input.
8 Initial Start-up
8.5 Configuring machine start and stop
No.: 9_9450 13 USE
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2
97
