8.5.1.4 Activating Timer control
Precondition The «Timer control» key is activated; see chapter 8.5.1.3.
➤ Press the «Timer control» key on the SIGMA CONTROL 2 operating panel to activate the timer
control.
Result The
Timer control
LED on the operating panel of the SIGMA CONTROL 2 signalizes with
green
continuous light
that the machine is operated with activated timer control.
The Timer control of SIGMA CONTROL 2 switches the machine according to the defined switching
points of the timer program.
8.5.2 Setting up the company shut-down
In addition to the fixed cycles of a timing program or timer, you can also specify a longer lasting
standstill time. For example, you may specify a standstill period for vacation shutdown by defining
the following:
Precondition Password access level 2 is activated.
1. Select the 5.4.2
<Configuration – Compressor start – Compressor off>
menu.
2. Use «Up» or «Down» to select the
Start
line.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.4.2 Compressor off
Menu
·········
Holidays : ☐
Start : 01/01/22
Active line
00:00AM
End : 01/01/22
03:00AM
3. Press «Enter».
The display for days
00.00.00
flashes.
4. Use «Up» or «Down» to set the day.
5. Press the «Right» key.
The display for months
00.00.00
flashes.
6. Use «Up» or «Down» to set the month.
7. Press the «Right» key.
The display for years
00.00.00
flashes.
8. Use «Up» or «Down» to set the years.
9. Press «Enter».
The setting is applied.
10. Press «Down».
11. Press «Enter».
The display for hours
00:00:00
flashes.
12. Use «Up» or «Down» to set the hours.
13. Press the «Right» key.
The display for minutes
00.00.00
flashes.
8 Initial Start-up
8.5 Configuring machine start and stop
No.: 9_9450 13 USE
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2
95
