KAESER SIGMA CONTROL 2 User Manual

2. Use «Up »or «Down» to set the AII input.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.2.4 Network actual pressure
Menu
AII 88.0psi
Active line (external pressure transducer)
AII1.01 ☐ 0.0psi
For sensor error:
Alarm
3. Press «Enter».
The AII input is set.
4. Press «Down».
The line for activating the input is displayed.
5. Press the «Right» key.
6. Press «Enter».
The check box assigned to the input flashes.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.2.4 Network actual pressure
Menu
AII 88.0psi
Active line
AII1.01 ok ☑ 0.0psi
For sensor error:
Alarm
7. Press «UP».
The check box is activated.
ok is displayed.
8. Press «Enter».
The setting is applied.
Result The input for the external transducer is now activated.
8.15 Commissioning the machine
Checking the controller settings Section Confirmed?
➤ Language correctly set? 8.2.2
➤ Date and time correct? 8.2.8
➤ Display format correctly set? 8.2.10
➤ System pressure setpoint correctly set? 8.4
Tab. 79 Check list for commissioning the machine
8 Initial Start-up
8.15 Commissioning the machine
172
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2 No.: 9_9450 13 USE

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
