13. Press the «Enter» key.
Setting mode is active.
14. Use «Up» or «Down» to set the required output
DOR
.
15. Press the «Enter» key.
The setting is applied accordingly.
16. Press the «Right» key.
17. Press «Enter».
The check box flashes.
18. Press the «Up» key.
The check box associated to output
DOR
is activated.
19. Press «Enter».
If output
DOR
is correctly assigned and activated,
ok
is displayed.
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
5.8 Timer
Menu
on :
01h:15m:00s
Cut-in period
off :
01h:15m:00s
Cut-out period
DOR1.03 ok ☑
Set output DOR
·········
current on
Current status DOR
00h:55m:34s
Remaining time until status change
Result The set output
DOR
is controlled by the timer.
The current status of output
DOR
is displayed in the
current
line. The remaining time until the next
status change is displayed in the line underneath.
8.13 Activating remote acknowledgement
When fault or alarm messages are routed to a remote control center via an output it makes sense
to have these messages acknowledged by the control center.
Acknowledging the message without correcting the cause, however, can lead to machine
damage.
Safety-relevant "EMERGENCY STOP push button" and "Maintenance door limit switch" mes‐
sages cannot be acknowledged remotely.
The following conditions must be fulfilled:
■ The remote control of the compressor is set (see chapter 8.5.3 Controlling machine from a re‐
mote location)
■ Remote control is activated (see chapter 8.2.13 Activating remote control)
■ A controller input has been assigned for the acknowledgement signal
Overview
■ Selecting the
<Configuration – Acknowledgement>
menu.
■ Setting the "Remote acknowledgement" function
■ Activating the remote control
8 Initial Start-up
8.13 Activating remote acknowledgement
168
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2 No.: 9_9450 13 USE
