Press «Enter» or one of the arrow keys to open the main menu. Here, you can set the language to
be used for the display of texts or open the various submenus.
5.3.1 Operating mode
8 8 p s i 0 8 : 1 5 A M 1 7 6 ° F
Header
------------------------------
Load
Current operating mode
------------------------------
Key – on ¦ pA – on
Operating parameters
------------------------------
Run 2500h Load 2490h
Operating parameters
Maintenance in 500h
Maintenance indicator
Header
The header is the topmost line on the display. It is always shown as white text on a black back‐
ground.
Important information and values are displayed in the header.
The displayed data varies depending on the machine type:
Type Header, left Header, center Header, right
SIGMA CONTROL 2
FLUID
Working gauge pressure Time Airend discharge temper‐
ature
SIGMA CONTROL 2
DRY
Pressure display reading
point
Pressure at the com‐
pressed air outlet
p100
Current operating mode
SIGMA CONTROL 2
VAC
Working gauge pressure Time Airend discharge temper‐
ature
SIGMA CONTROL 2
BLOWER
p2 (final pressure) Time Discharge temperature T2
SIGMA CONTROL 2
BOOSTER
Pressure at the com‐
pressed air inlet p1
Temperature at the
compressed air out‐
let T2
Pressure at the com‐
pressed air outlet p4
SIGMA CONTROL 2
PISTON
Working gauge pressure – Time
Tab. 28 Data in the header depending on the machine type
Lines 3 and 5: Operational state
Depending on the settings, either the current state of the machine or a menu text is shown in line 3.
The following parameters with their current values are displayed in line 5:
■ Remote control yes/no
■ Timer control yes/no
■ Pressure control
5 Design and Function
5.3 Display
No.: 9_9450 13 USE
User Manual Controller
SIGMA CONTROL 2 SCREW FLUID ≥5.1.2
23
